Electrophoretic Lacquer (PU Based)
Enhance durability, safety, and visual appeal with our PU-based Electrophoretic Lacquer, an advanced coating technology designed to deliver flawless finishes and long-term protection. Using a controlled electro-deposition process, the coating forms a smooth, uniform layer that protects even the most intricate components.
Why Choose Electrophoretic Lacquer?
- Up to 20 years corrosion protection (depending on environment & substrate)
- Excellent electrical insulation properties
- Uniform coating even on complex shapes and edges
- Consistent shade and thickness across production batches
- High adhesion strength with minimal rejection rates
- Suitable for both decorative and functional applications
- Improved production efficiency with controlled automation
Our capabilities (at a glance)
- PU-based electrophoretic lacquer coating
- Gloss, semi-gloss & matte finish options
- Wide color spectrum customization
- Plastic & metal substrate compatibility
- Batch and mass-production support
- Integrated pre-treatment & curing systems
- OEM and Tier-1 project support
What We Coat
- Automotive trims & functional parts
- Electrical components requiring insulation
- Decorative hardware & fittings
- Appliance components
- Industrial precision parts
- Premium lifestyle product components
Our Electrophoretic Lacquer Process
Substrate Evaluation & Feasibility
We begin with material compatibility analysis to ensure optimal adhesion and long-term durability.
- Substrate identification (metal / plated parts / engineered plastics)
- Surface condition inspection
- Adhesion feasibility testing
- Coating thickness and finish requirement review
Surface Preparation & Pre-Treatment
Surface preparation is critical for long-term protection.
- Degreasing & alkaline cleaning
- Rinsing & surface activation
- Controlled drying process
- Surface inspection before coating
Electrophoretic Deposition (E-Coating Process)
Using a controlled electro-deposition system:
- Components immersed in lacquer bath
- Electrical current applied for uniform deposition
- Self-leveling coating formation
- Complete coverage including edges and recesses
- Controlled film thickness build (15–25 microns or customized)
Curing & Film Hardening
- Thermal curing in calibrated ovens
- Cross-linking of PU polymer for durability
- Enhanced hardness and chemical resistance
- Controlled cooling to prevent surface defects
Post-Coating Inspection & Handling
- Visual inspection under controlled lighting
- Film thickness measurement
- Adhesion & insulation verification
- Scratch-free handling and packaging
In-Process Quality Checks
- Film thickness control (micron-level precision)
- Cross-hatch adhesion test (ISO 2409 / ASTM D3359)
- Salt spray resistance validation (ASTM B117)
- Electrical insulation testing
- Surface finish & gloss measurement
- Batch traceability documentation
Technical Specifications
- Coating Type: Polyurethane (PU) based electrophoretic deposition
- Typical Film Thickness: 15 – 25 microns (customizable)
- Salt Spray Resistance: 500 – 1,000+ hours (ASTM B117, substrate dependent)
- Adhesion: Excellent (ISO 2409 / ASTM D3359 compliant)
- Curing Method: Thermally cured
- Finish Options: Gloss / Semi-gloss / Matte
How We Ensure Long-Term Performance
- Controlled bath chemistry monitoring
- Automated voltage & deposition control
- Clean handling zones to prevent contamination
- Standardized curing profiles
- Consistent batch recipes for color and thickness repeatability
Safety Guidelines & Compliance (Shop-Floor Level)
- Electrical safety protocols for deposition systems
- Controlled chemical storage & handling
- PPE compliance for all operators
- Fire safety & oven monitoring systems
- Environmentally compliant waste handling
- Regular equipment calibration & maintenance
What’s Best for You (Client Benefits)
For Automotive & Electrical Applications
- Long-term corrosion resistance
- Reliable electrical insulation
- Uniform finish on intricate geometries
- Reduced warranty risks
For Premium & Decorative Products
- High aesthetic consistency
- Multiple finish options
- Enhanced perceived product value
- Durable protective top layer
